4G Industrial Cellular Router
Product ID: TR-244
TR-244 4G Industrial Cellular Router is an industrial grade cellular router designed with industrial grade protection, wide temperature range, wide voltage range, etc. It can easily build a high-speed and stable cellular transmission network.
-
Network
4G LTE+4*LAN 100Mbps
-
Interface
RS485x1 + RS232x1
-
Temperature
-40°C~75°C
-
Power
12-36V
Get Free Quote Now
Download
TR-244 5G Industrial Cellular Router Video
The TR-244 5G Industrial Cellular Router video showcases ultra-fast connectivity, rugged design, secure networking, remote access, and reliable performance for industrial IoT and automation deployments.
Features
Product Introduction
TR-244 is an industrial grade cellular router designed with industrial grade protection, wide temperature range, wide voltage range, etc. It can easily build a high-speed and stable cellular transmission network. Provide cellular long-distance data transmission services to users using public LTE networks (or VPDN proprietary networks). It has the characteristics of strong universality, standardized interfaces, wide application industries, stable performance, and applicability to complex environments. It can be widely used in various industrial Internet, intelligent transportation, robots and other industries around the world.
Comprehensive Network Redundancy
Ensures uninterrupted connection with 4G full - band, WiFi 802.11n (up to 300Mbps), dual SIM standby, triple backup switching (wired/WiFi/4G), and 5 auto - adaptive 100Mbps Ethernet ports.
Dual - path Wide - voltage Power Supply
Adopts DC 5 - 30V wide - range input, with two power supply methods (DC jack and terminal) for redundancy, suitable for complex industrial power environments, and current consumption is less than 400mA.
Industrial - grade Installation Design
With a compact size of 93×118×24mm (excluding antenna) and DIN rail mounting, it's easy to deploy in industrial setups, saving space.
Excellent Performance in Harsh Environment
Works stably in a temperature range of -20℃ to 75℃ (storage: -40℃ to 80℃) and 5 - 95% non - condensing humidity, suitable for harsh industrial conditions.
Tech Specs
Metering Equipment Technical Data
| Items | Features | |
| Power supply | DC power supply : 12-36V | |
| cellular interface | IEEE 802.11 a/b/g/n/ac | |
| Operating frequency band | 2.4G:2.4-2.4835GHz 5G:5.180-5.885GHz | |
| Main chip | MTK series | |
| Antenna | SMA external rotation inner hole | |
| WIFI transmission rate | 7628：300Mbps | |
| 7621：1200Mbps | ||
| External interface | LAN ports: 5 100Mbps Ethernet ports (LAN0 is WAN/LAN adaptive) |
|
| SIM card slot: double-layer | ||
| Antenna interface: 4 | ||
| Indicator lights: 8 | ||
| DC power supply interface: 1 (DC2.1) | ||
| Reset button: 1 | ||
| 4G LTE+4*LAN 100Mbps | ||
| 1*RS485;1*RS232 | ||
| Data rate | 802.11n: up to 300Mbps | |
| 802.11b: 1, 2, 5,5, 11Mbps | ||
| 802.11g: 6, 9, 12, 18, 24, 36, 48, 54Mbps | ||
| Transmit power | 11n HT40 MCS7 : +13.5dBm | |
| 11bCCK: +18 dBm | ||
| 11gOFDM: +13.5dBm | ||
| Receiving sensitivity | -66dBm at 150 Mpbs | |
| -73dBm at 54Mpbs | ||
| -86dBm at 11Mpbs | ||
| Overall dimensions | Length, width, and height: 116 * 134 * 34mm (antenna interface) |
|
| Power consumption (current) | Less than 400mA | |
| Working environment | Working temperature: -40 ° C~+75 ° C | |
| Storage temperature: -40 ° C~+80° C | ||
| Humidity: 5%~95%, no condensation | ||
Product Dimensions
Explore our Solutions
Smart Metering Communication Solutions
Offering multi-protocol optical acquisition products for stable and efficient data transmission across diverse metering needs.
Case
Product Case
Tespro TR-324 is widely used in electric power, industrial communications, industrial control, environmental monitoring, water conservancy, transportation, municipal administration, smart home, self-service terminals, robotics and other industries
